     ※ Now : Products center >> >> Medium-RO reverse osmosis water system

    With microcomputer controlling system in LED display, stainless steel shell, built-in 2 set pressure tanks, single stage RO system, 1 pump, portable TDS test pen and on-line conductivity monitor, Medium-RO series reverse osmosis water system is economic choice of RO water’s mass usage for general glassware washing. With tap water inlet, its output ranges from 45 to 125 liters/hour. It can produce single stage RO water. The single stage RO water’s ion rejection rate is more than 97% (new RO membrane), organic rejection rate>99% (when mw>200 Dalton), particles and bacteria rejection rate>99%. It is suitable for glassware washing, feed of ultrapure water system, autoclave sterilizer, constant temperature and humidity chamber, salt spray test chamber, dampening machine and etc.

    Flow Schematic

    Specifications

    Model Medium-RO300 Medium-RO400 Medium-RO600 Medium-RO800
    Output(25°C)* 45 liters/hour 63 liters/hour 94 liters/hour 125 liters/hour
    Pure water outlet 1: reverse osmosis water
    RO water quality ? ? ? ?
    Ion rejection rate 97%-99% (new RO membrane)
    Organic rejection rate >99%, when MW>200 Dalton
    Particles and bacteria rejection rate >99%
    Bacteria <0.01cfu/ml(with optional 0.2μm PES terminal filter)
    Particle(>0.2μm) <1/ml(with optional 0.2μm PES terminal filter)
    Feed water requirements Tap water, temperature:5-45°C,pressure:1.0-4.0Kgf/cm2
    Dimension and weight Length×Width×Height:640×540×1110mm / Weight: about 60Kg
    Electrical requirements AC110-240V, 50/60Hz
    Power 120W 240W
    Standard configuration Main body (Including 1 set of cartridge)+2 set built-in 15 liters pressure tank+ TDS/conductivity test pen
    Remarks:
    *The value will be influenced by temperature and feed water’s quality.

    Cartridges

    Item no. Commodity Approximate replacement term /set
    PC-20PP 20" spun fiber cartridge 2-6 months
    PC-20AC-G 20" granular active carbon cartridge 2-6 months
    PC-20AC-B 20" active carbon block cartridge 2-6 months
    RO-150GPD 150 GPD reverse osmosis membrane 12-24 months
    RO-200GPD 200 GPD reverse osmosis membrane 12-24 months
    RO-300GPD 300 GPD reverse osmosis membrane 12-24 months
    RO-400GPD 400 GPD reverse osmosis membrane 12-24 months
    RO-600GPD 600 GPD reverse osmosis membrane 12-24 months
    PTC-AC-HZB1 Reducing TOC cartridge 9000 liters pure water
    PTC-MBR-12L 12l mixed bed resin cartridge 20000 liters pure water
    PTC-UPPR-12L 12l ultrapure polishing resin cartridge 20000 liters pure water
    PTC-MBR-25L 25l mixed bed resin cartridge 40000 liters pure water
    PTC-UPPR-25L 25l ultrapure polishing resin cartridge 40000 liters pure water
    PTC-UPPR-M Ultrapure polishing resin cartridge 1000 liters pure water/set
    TF-0.2µm-B 0.2µm terminal filter -
    UF-5000D MWCO5000D UF cartridge -
    LAMP-(185nm&254nm)-10W-M Double wavelength(185&254)nm uv lamp 9000 hours
